Part Number

131745618021

Parts For Repair Only

Specifications:
Volts:12V
KiloWatts:2.5KW
Overall Length:295mm
Mounting Hole:13mm
Mt Holes Centre:142mm
Flange Diameter:90mm
Nose Cone Length:38mm
Pinion at Rest:16mm
Field Housing Diameter:90mm
Teeth:12TH
Rotation:CW
Pinon Diameter:45mm

Note

Please Check With Pictures / Numbers / Specs Before Ordering.

Fitment

Fit For Toyota Landcruiser PZJ70 5Cyl. eng.1PZ 3.5L 1990-1993

Fit For Toyota Landcruiser PZJ73R 3.5L 5cyl Diesel 1PZ 08/1989 - 07/1992

Fit For Toyota Landcruiser PZJ75 5Cyl. eng.1PZ 3.5L 1990-1991

Fit For Toyota Landcruiser HZJ70 eng.1HZ, 4.2L 1990-1999

Fit For Toyota Landcruiser HZJ73R 4.2L 6cyl Diesel 1HZ 01/1990 - 07/1991

Fit For Toyota Landcruiser HZJ75R 4.2L 6cyl Diesel 1HZ 01/1990 - 07/1999

Fit For Toyota Landcruiser HZJ78R 4.2L 6cyl Diesel 1HZ 08/1999 - 2007

Fit For Toyota Landcruiser HZJ79R 4.2L 6cyl Diesel 1HZ 08/1999 - 2007

Fit For Toyota Landcruiser HZJ80R 4.2L 6cyl Diesel 1HZ 01/1990 - 1998

Fit For Toyota Landcruiser HZJ105R 4.2L 6cyl Diesel 1HZ 01/1998 - 07/2007

Fit For Toyota Landcruiser HDJ78R 4.2L 6cyl Turbo Diesel 1HD-FTE 08/1999 - 07/2007

Fit For Toyota Landcruiser HDJ79R 4.2L 6cyl Turbo Diesel 1HD-FTE 08/1999 - 07/2007

Fit For Toyota Landcruiser HDJ80R 4.2L 6cyl Turbo Diesel 1HD-FT 08/1994 - 07/1999

Fit For Toyota Landcruiser HDJ80R 4.2L 6cyl Turbo Diesel 1HD-T 08/1990 - 1998

Fit For Toyota Landcruiser HDJ81 4.2L 6cyl Turbo Diesel 1HD-T 08/1990 - 07/1994

Fit For Toyota Landcruiser HDJ100R 4.2L 6cyl Turbo Diesel 1HD-FTE 08/2000 - 07/2007

Fit For Toyota Landcruiser HDJ101 4.2L 6cyl Turbo Diesel 1HD-FTE 08/1998 - 07/2002

Fit For Yanmar Diesel 6LP-DTE

Fit For Yanmar Diesel 6LP

Package:
1 x Starter Motor
