Note

Please Check With Pictures / Numbers / Specs Before Ordering

Specification

Volts：12

Amps：220

Adjustment Hole (mm)：11

Pivot Hole (mm)：11/M10x1.25

Adjustment To Pivot (mm)：127

Pivot Length (mm)：/

Inside Feet To Feet (mm)：76

Pulley (mm)：55

No Of Grooves：6PV

Plug：RP264

OEM Part Numbers

TG23C012 / 11451 / 116188 / 0986083460 / 0986UR6371 / CA2100IR / 2543223 / 2543223A / 439606 / 440109 / LRA03242 / LRA3242 / DRA0593 / 12317801124 / 12317804266

Fitment

Fit For BMW 118D E87 Engine N47D20 2.0L Turbo Diesel 2006-2010

Fit For BMW 118D E88 Engine N47D20 2.0L Turbo Diesel 2009-2015

Fit For BMW 118D F20 Engine N47D20C 2.0L Turbo Diesel 2011-2015

Fit For BMW 120D E82 Engine N47D20 2.0L Turbo Diesel 2006-2010

Fit For BMW 123D E82 Engine N47D20 2.0L Turbo Diesel 2008-2014

Fit For BMW 123D E87 Engine N47D20 2.0L Turbo Diesel 2008-2011

Fit For BMW 123D E88 Engine N47D20 2.0L Turbo Diesel 2008-2018

Fit For BMW 220D F22 Engine N47D20O 2.0L Turbo Diesel 2014-2015

Fit For BMW 318D F30 Engine N47D20C 2.0L Turbo Diesel 2012-2014

Fit For BMW 318D F31 Engine N47D20C 2.0L Turbo Diesel 2012-2015

Fit For BMW 320D E90 E91 Engine N47D20 2.0L Turbo Diesel 2008-2012

Fit For BMW 330D E92 Engine N47D20 2.0L Turbo Diesel 2006-2014

Fit For BMW 330D E93 Engine N47D20 2.0L Turbo Diesel 2009-2014

Fit For BMW 330D F30 Engine N47D20C 2.0L Turbo Diesel 2012-2015

Fit For BMW 330D F34 Engine N47D20C 2.0L Turbo Diesel 2013-2017

Fit For BMW 330D E90 Engine N57D30A 3.0L Turbo Diesel 2009-2012

Fit For BMW 330D E92 E93 Engine N57D30A 3.0L Turbo Diesel 2010-2013

Fit For BMW 420D F32 F33 F36 Engine N47D20C 2.0L Turbo Diesel 2013-2016

Fit For BMW 520D F07 Engine N47D20C 2.0L Turbo Diesel 2012-2017

Fit For BMW 530D F07 Engine N57D30A 3.0L Turbo Diesel 2010-2017

Fit For BMW 535D F10 Engine N57D30D 3.0L Turbo Diesel 2010-2013

Fit For BMW 535D F10 Engine N57D30B 3.0L Turbo Diesel 2013-2017

Fit For BMW X1 E84 Engine N47D20C 2.0L Turbo Diesel 2010-2015

Fit For BMW X1 E84 Engine N47D20D 2.0L Turbo Diesel 2010-2012

Fit For BMW X3 E83 Engine N47D20 2.0L Turbo Diesel 2007-2011

Fit For BMW X3 F25 Engine N47D20C 2.0L Turbo Diesel 2011-2014

Fit For BMW X3 F25 Engine N57D30A 3.0L Turbo Diesel 2011-2017

Fit For BMW X4 F26 Engine N57D30A 3.0L Turbo Diesel 2014-2018

Fit For BMW X4 F26 Engine N57D30B 3.0L Turbo Diesel 2014-2018

Fit For BMW X5 E70 Engine N57D30A(B) 3.0L Turbo Diesel 2010-2013

Fit For BMW X5 F15 Engine N47D20B 2.0L Turbo Diesel 2013-2014

Fit For BMW X5 F15 Engine N57D30A(B C) 3.0L Turbo Diesel 2013-2018

Fit For BMW X5 3.0d/xDrive 35d 2008-2013

Fit For BMW X6 E71 E72 Engine N57D30A(B C) 3.0L Turbo Diesel 2011-2014

Fit For BMW X6 F16 F86 Engine N57D30A(B C) 3.0L Turbo Diesel 2015-2018

Fit For BMW X6 xDrive 30d 2008-2014

Package

1 x Alternator
