Feature

1. TÜV PRODUCT TEST AND TÜV ISO 9001 CERTIFIED.

2. Material: Forged SAE 4340 Chrome Moly Steel for the highest strength and durability, dedicated for Racing.

3. ARP 2000 bolts, Optional ARP L19 fasteners available as an upgrade.

4. H-Beam design reduces weight without compromising strength.

5.Heat-treating & Shot-peened for remained consistent and strong. Shot-peened finish to remove potential for stress risers.

6.High precision CNC machined,Precision rod cap alignment dowels.

7.Bores finished to +/- .005mm.

8.Balanced to within +/- 1 g per rod.

9. Each rod is magnetic particle tested to ensure free of flaws.

10.Use X-rayed, sonic tested.

Specification

Type: Forged 4340 aircraft chrome moly quality steel for racing

H-beam Conrods Quantity: 4 Pieces a set

Bolts size: Genuine ARP 2000 5/16" bolts

Note: Extra cost for upgrading to ARP L19 bolts

Tolerance: Balanced to +/- 1 gram in set

Power: 600hp ~ 800PS per set

Strength of the fastening (PSI): 220,000/230,000 PSI

Torque: 28ft

Top acceleration: 7000rpm

Center to center length: 103mm

Big end diameter: 37mm

Small end diameter: 17mm

Big end width: 21.9mm

Small end width: 14.5mm

Note:Press fit, no bushing

Fitment

Fit For BMW S1000RR / K46 999cc

Package

4 x Connecting Rods
