Product Description

Ultimate9 Nudge Bars Provide a Layer Of Protection For The Front Of Your Vehicle To Shield Vital Components Such As The Radiator In The Event Of An Accident.

Their Design Has a Low Impact On Front-End Weight And Also Functions As a Mounting Platform With Provision For UHF & Mobile Phone Antennas, Sand Flags And Additional Ultimate9 LED Light Bars.

Designed, Engineered And Manufactured In Australia With Australian 3mm Steel, The Low-Profile, Over-Bumper Design Offers Minimal Forward Projection And Is Packaged With An Ultimate9 LED Light Bar Nestled In The Front Face.

Finished In a Black Textured Powder Coat With a Silver Coated Centre Pan For Corrosion Protection And a Modern Feel.

Feature

Australian-Made: Designed, Engineered, And Manufactured In Australia.

Steel Frame: 100% Australian-Made Steel.

Airbag Compatible: Tested For Airbag Compatibility

ADR Compliant: Designed To Meet ADR Standards.

Low Profile: Over Bumper Design With Minimal Forward Projection

LED Lighting: Includes An Ultimate9 LED Light Bar 30"

Lightweight: Weighing Under 30Kg With Included Light Bar

Corrosion Protected: Zinc-Plated.

Finish: Black Textured Powder-Coat With Silver Powder-Coated Centre Pan

Specification

Material (Nudge Bar): 3mm Steel

Material (Centre Pan): 1.6mm Steel

Material (Mounts): 6mm Steel

Protective coat: Zinc Plated

Finish Coat (Nudge Bar): Black Textured Powder Coat

Finish Coat (Centre Pan): Silver Powder Coat

ADR Compliant

Airbag Compatible

Fitment

Fit For Ford Ranger Raptor 2nd Gen Next-Gen T6.2 2022-ON

Optional Lighting

The Ultimate Nudge Bar To Suit Ford Ranger Raptor 2022 - ON (Next-Gen, T6.2 - 2nd Gen) Includes Laser-Cut Points To Fit An Additional Light Bar On Top Of The Nudge Bar.

Light Bar Sizing Required To Suit Laser-Cut Points:

Ultimate9 LED Light Bar 26" - Top

Package

Nudge Bar

Ultimate9 LED Light Bar 30"

DTP Connector Kit

Parking Sensor Extension Looms

Parking Sensor Holders

Parking Sensor Blanking Plates

Slimline Number Plate Mount

Installation Hardware

Instructions
