Feature

Product Material

1. Turbine housing: Ductile iron QT450-10 - temperature resistant up to 700℃

2. Steel turbine wheel: K418 alloy - high oxidation stability and resistance up to 900℃

3. Compressor housing: ZL104 aluminum with lightweight

4. Compressor wheel/blades: Cast aluminium blades - superior air tightness & corrosion resistance

Product Performance

1. Cost-effective turbo increase 20-40% power for your car

2. Rich experience in turbo production and own factory

3. High-Speed oil seal ring and Precision clearance

4. Built for durability and strength

Technology Advantage:

1. 100% balancing Test by TURBOTECHNICS VSR3

2. G3-min-Flow VNT Turbo testing

3. Advanced Actuator Tester/Programmer

Specification

Horse Power: Boost Horse Power up to 500BHP

Cooling Type: Water + Oil

Internal Wastegate Actuator Setting: Up to 4.35psi

Exhaust Inlet (Turbo Manifold) Flange: 4 bolts Flange

Exhaust Outlet Flange: 6 bolts Flange

Oil Inlet: M12*1.25 & 2*M8*1.25

Oil Outlet: 2*M8*1.25

Oil Return: 18 / side hole:M8*1.25

Center-center: 50.8

Water Hole: M18*1.5

Compressor Inducer Diameter: 52.7 mm

Compressor Exducer Diameter: 76mm

Compressor Trim: 48.1

Compressor A/R: 0.5

Turbine Inducer Diameter: 64.4mm

Turbine Exducer Diameter: 47.9mm

Turbine Trim: 55.3

Turbine A/R: 0.63

Additional Details:

Bearing: Wet Float

Wastegate: With Wastegate

Accessories: You Will Get Exactly As Shown In The Picture Above

Fitment

Fit for Nissan Skyline R32 R33 R34 2.0L-2.5L RB20DET RB25DET engine

For some R33 models few modifications may be required( A direct Bolt on turbo upgrade for RB20DET and RB25DET for Skyline Engines! Will require a coupler to connect turbo to hotpipe but other than that its a OEM Bolt on with upgrade 3" air inlet and larger wheels for optimum power. )

Package

1x Carburetor

1x Black Throttle Base Cover

1x Throttle Base Cover Screw

(You Will Get Exactly As Shown In The Picture Above)
